AEMC 205 - DC Current Measurement; AC Current Measurement

37
Specific Specifications in MAX/MIN mode in voltage
(from 10Hz to 1kHz in AC and AC+DC, and from 0.30V):
• Accuracy: add 1% R to the values of the previous table.
• Capture of the extreme: approximately 100ms.
Specific Specifications in PEAK mode in voltage
(from 10Hz to 1kHz in AC and AC+DC):
• Accuracy: add 1.5% R to the values in the previous table.
• PEAK capture time: 1ms min. to 1.5ms max.
4.2.4 DC Current Measurement
Measurement
Range
(2)
0.00 to
59.99A
60.0 to
599.9A
600A to 900A
(1)
Specified
Measurement Range
0 to 100% of the measurement range
Accuracy
(2)
(zero corrected)
± (1% R +10cts) ± (1% R +3cts)
Resolution
0.01A
0.1A
1A
Note (1) The display indicates “+OL” above 1800A and “-OL” below -1800A
in REL mode. The "-" and "+" signs are displayed.
Note (2) The residual current at zero depends on the remanence. It can be
corrected by the “DC zero” function of the HOLD button.
4.2.5 AC Current Measurement
Measurement
Range
(2)
0.15 to
59.99A
60.0 to
599.9A
600A
(1)
Specified
Measurement
Range
0 to 100% of the measurement range
Accuracy
± (1% R +10cts)
± (1% R +3cts)
Resolution
0.01A
0.1A
1A
Note (1) The display indicates "OL" above 900A (in PEAK mode). The "-" and
"+" signs are not managed.
- Bandwidth in AC = 3 kHz
Note (2) In AC, any value between zero and the min. threshold of the
measurement range (0.15A) is forced to show “----“ on the display.
