1 PRESENTATION
The Clamp-on Meter Model 205 is a professional electrical measuring instrument
that combines the following functions:
 Current measurement
 Measurement of InRush current / overcurrent (True InRush
®
)
 Voltage measurement
 Frequency measurement
 Measures harmonic distortion (THD)
 Continuity test with buzzer
 Resistance measurement
 Diode test
 Power measurements (W, VA, var and PF)
 Phase order indication
Item Designation See §
1
Jaws with cente
ring marks
(see connection principles)
3.5 to
3.12
2 Physical Guard -
3 Rotary Function Switch 1.1
4 Function Buttons 2
5 Backlit Display 1.3
6 Input Terminals 1.4
7 Trigger -
Figure 1: Clamp-on Meter Model 205
