NETBOX 8 AD.
Inputs / Outputs
Labels in NetBox Tool
Transmission / reception channels
Labels in DANTE Controller
ANALOG 01 L NBOX8_1L
ANALOG 01 R NBOX8_1R
ANALOG 02 L NBOX8_2L
ANALOG 02 R NBOX8_2R
DIGITAL 03 L NBOX8_3L
DIGITAL 03 R NBOX8_3R
DIGITAL 04 L NBOX8_4L
DIGITAL 04 R NBOX8_4R
NETBOX 32 AD.
Inputs / Outputs
Labels in NetBox Tool
Transmission / reception channels
Labels in DANTE Controller
ANALOG 01 L NBOX32_1L
ANALOG 01 R NBOX32_1R
ANALOG 02 L NBOX32_2L
ANALOG 02 R NBOX32_2R
ANALOG 03 L NBOX32_3L
ANALOG 03 R NBOX32_3R
ANALOG 04 L NBOX32_4L
ANALOG 04 R NBOX32_4R
ANALOG 05 L NBOX32_5L
ANALOG 05 R NBOX32_5R
ANALOG 06 L NBOX32_6L
ANALOG 06 R NBOX32_6R
ANALOG 07 L NBOX32_7L
ANALOG 07 R NBOX32_7R
ANALOG 08 L NBOX32_8L
ANALOG 08 R NBOX32_8R
DIGITAL 09 L NBOX32_9L
DIGITAL 09 R NBOX32_9R
DIGITAL 10 L NBOX32_10L
DIGITAL 10 R NBOX32_10R
DIGITAL 11 L NBOX32_11L
DIGITAL 11 R NBOX32_11R
DIGITAL 12 L NBOX32_12L
DIGITAL 12 R NBOX32_12R
DIGITAL 13 L NBOX32_13L
DIGITAL 13 R NBOX32_13R
DIGITAL 14 L NBOX32_14L
DIGITAL 14 R NBOX32_14R
DIGITAL 15 L NBOX32_15L
DIGITAL 15 R NBOX32_15R
DIGITAL 16 L NBOX32_16L
DIGITAL 16 R NBOX32_16R
NOTE 1: When there is more than one NETBOX in the system, the devices could be labelled in
"Dante Controller" as NETBOX4MH-01, NETBOX4MH-02… NETBOX4MH-n, as NETBOX8-01,
NETBOX8-02… NETBOX8-n or as NETBOX32-01, NETBOX32-02… NETBOX32-n in order to
identify them (or with any other name that allows to identify them easily on each installation).
NOTE 2: In the case of NETBOX DSP 64 the names of the transmission / reception channels in
"Dante Controller" are NBOXDSP_1L, NBOXDSP_1R, NBOXDSP_2L... NBOXDSP_31R,
NBOXDSP_32L and NBOXDSP_32R.
In the case of NETBOX DSP 96, "Dante Controller" will show the main module with the
previously described channels and a second device corresponding to the additional module with
32 transmission / reception channels (named as NBOXDSP_1L, NBOXDSP_1R,
NBOXDSP_2L... NBOXDSP_15R, NBOXDSP_16L and NBOXDSP_16R).
