AERMEC MODUCONTROL Usage Manual

64
GB
6343841_00 / Ver - 4.20
Serial communication protocol
The Modu_Control card manages (towards the BMS/VMF supervisor) both
the Register values (whole/analogue) and the Coil values (digital). The
commands that can be used to read/write these values are:
MODBUS commands
DIGITAL VALUES LIST (COIL):
To be able to write the COIL parameters on
the Modu_Control card, you must enable the
supervision commands by setting the parameter
parameter (N) = 1 of the installer menu
(password=30) of the panel on the machine.
!
ADDRESS DESCRIPTION
0 Standby/On command (toggle) 0=OFF 1=ON
1 Operation mode command (toggle) 0=COOL 1=HEAT
2 Domestic water remote command 0=Normal, 1=Domestic
3 Enable remote thermostat 0=Disabled, 1=Enabled
4 Alarm reset command 1=Alarm reset
5 Compressor1 status 0=OFF 1=ON
6 Compressor2 status 0=OFF 1=ON
7 Boiler/electric heater status 0=OFF 1=ON
8 Hot domestic water production status 0=not active 1=active
9 Domestic water ID status 0=ID closed – 1=ID open
10 Remote ON_OFF ID status 0=ID closed – 1=ID open
11 Season ID status 0=ID closed (cool), 1=ID open (heat)
12 Room thermostat ID status 0=ID closed – 1=ID open
13 Alarm summary
14 Pre-alarm summary
15 Compressor thermomagnetic switch pre-alarm
16 Fan thermomagnetic switch pre-alarm
The Modu_control card allows an inter-
face with a centralised system via a spe-
cial serial expansion card based on the
RS485 electric standard and using the
Modbus RTU standard protocol.
The Modu_Control card is always the
slave of the communication.
To enable communication from a supervi-
sion system to the Moducontrol card, you
must set the following parameters:
• Parametro J - Ad1 (Indirizzo modbus
del supervisore);
• Parametro L - Bd1 (Baudrate supervisore);
It is also necessary to ensure compliance
with the following characteristics:
• Stop bits: 2;
• Parity: NONE;
Codici MODBUS utilizzati
cmd descrizione
0x01 Read Coil Status
0x03 Read Holding Registers
0x05 Force Single Coil
0x06 Preset Single Register
0x0F Preset Multiple Coils
0x10 Preset Multiple Registers
COMANDI DIGITALI DISPONIBILI
Read Coil Status
Force Single Coil
Force Multiple Coils
