LOCAL OPERATION
3-86
The radio identification code (RIC) of the radio pager is set by the user. This is entered into the
Service Monitor as a seven digit decimal number corresponding to the 21 bit address code of the
radio pager. The number is unique to the radio pager and will have a maximum decimal
equivalent of 2097151.
Leading zero can be omitted from the entry of RIC to save time.
C1883
Level
Select
mess
Alert
type
Alert
type
Address/Alert Type messages
are selected by repeatedly pressing
the key
Table showing one possible
arrangement of responses to
differing function bit combinations
Function Bit
Combination
(00)
(01)
(10)
(11)
Following
Message Type
Numeric-only
No message
No message
Alpha-numeric
Alerting
Tones
1beep
2 beeps
3 beeps
1beep
Fig. 3-25 Alternative address/warning messages
