LOCAL OPERATION
3-11
HELP/SETUP
Pressing the [HELP/SETUP] key, at any time, will display the screen shown in fold out diagram
(1-0), or a variation of it. Displaying the HELP/SETUP screen does not interrupt any ongoing
operation or test.
The center panel of the screen lists the following information:
Serial number of the Service Monitor
Software fitted, with the version codes and part numbers.
Help
The help facility is accessed by using the [HELP] key. Each soft key in the help menu displays
‘On Screen Help’ relating to the blue system key to the left of it. The [Return] key removes the on
screen help and displays the top-level screen of the mode from where HELP/SETUP was selected.
Self Test
Pressing this key gives access to the SELF TEST function of the Service Monitor. Refer to Self
tests and acceptance tests in Chapter 2, for details.
Diagnostic
The DIAGNOSTIC screen can only be accessed by entering a protection code. When accessed, it
allows a low level of software fault diagnosis to be undertaken. Certain areas of memory can also
be reset from this screen. Details of access are given in the maintenance manual relating to this
instrument.
Calibrate
Access to the CALIBRATION screen is also code-protected. Details relating to access and use are
given in the maintenance manual relating to this instrument.
Backlight
This key is the ON / OFF control for the display backlight.
Brightness
Selecting this key allows the illumination level of the display backlight to be varied using the
variable control. The illumination level can also be adjusted by the entering a number between 0
and 255 using the data input keys.
Options Fitted
Shows which options are fitted to the Service Monitor (except Option 3).
Setup
RF Setup
Press this key to allow selection of RF generator facilities options: the description starts on
page 3-15. RF setup is shown in fold-out diagram (1-10-2). The keys described may differ if
some options are fitted. See the descriptions relating to those options for details.
AF Setup
Press this key to allow selection of AF level measurement units, GPIB address setting, remote
control option selection and serial port setup: the description starts on page 3-17. AF setup is
shown in fold-out diagram (1-10-3).
The keys described may differ if some options are fitted. See the descriptions relating to those
options for details.
