ACCEPTANCE TESTING
5-45
Results table 5-24 Audio generator 2 frequency (functional)
AF generator 2
setting
Lower
limit
Upper
limit
Result
10 Hz 9.9 Hz 10.1 Hz _______
500 Hz 499.9 Hz 500.1 Hz _______
1.0000 kHz 999.9 Hz 1000.1 Hz _______
1.1111 kHz 1.1110 kHz 1.1112 kHz _______
2.2222 kHz 2.2221 kHz 2.2223 kHz _______
3.333 kHz 3.3328 kHz 3.3332 kHz _______
4.444 kHz 4.4438 kHz 4.4442 kHz _______
5.555 kHz 5.5548 kHz 5.5552 kHz _______
6.666 kHz 6.6658 kHz 6.6662 kHz _______
7.777 kHz 7.7768 kHz 7.7772 kHz _______
8.888 kHz 8.8878 kHz 8.8882 kHz _______
9.999 kHz 9.9988 kHz 10.0010 kHz _______
15.000 kHz 14.999 kHz 15.0010 kHz _______
20.000 kHz 19.9989 kHz 20.0011 kHz _______
Results table 5-25 Audio frequency meter
LF generator
frequency
Level
(mV)
Lower
limit
Upper
limit
Result
20 Hz 50 19.8 Hz 20.2 Hz _______
1 kHz 50 999.8 Hz 1000.2 Hz _______
20 kHz 50 19.9989 kHz 20.0011 kHz _______
