10
Chapter 1: General Information
Accessories
One or more of the following accessories, sold separately, are required to operate
the 16753/54/55/56A or 16950A logic analyzer.
Mainframe and Operating System
The 16753/54/55/56A logic analyzers require a 16700-series logic analysis system
with operating system version A.02.70.00 or higher, or any 16900-series logic
analysis system.
The 16950A logic analyzer requires a 16900-series logic analysis system.
To check your 16700-series logic analysis system’s operating system version
number, open the System Administration window, click the Admin tab, then click
About...
If the proper version is not loaded, obtain a copy of the updated operating system
software and install it in the logic analyzer mainframe. You can request a software
upgrade at http://software.cos.agilent.com/16700 or by contacting your nearest
Agilent Technologies Customer Support Center.
Three Cooling Fans Required in 16700A-series Mainframe
Earlier versions of the 16700A/01A/02A mainframe contained only two cooling
fans and might not provide adequate cooling to ensure reliable performance. If
the first six digits of the 16700A/02A serial number (located on the back of the
instrument) are US3849 or higher, or the first six digits of the 16701A are US3902
or higher, the instrument is a three-fan model, which will supply sufficient
cooling.
All 16700B/01B/02B and all 16900-series systems provide adequate cooling to
ensure reliable performance.
Accessories Agilent Part Number
Single-ended soft touch probe E5390A
Differential soft touch probe E5387A
Half-size soft touch probe E5398A
100-pin single-ended probe E5378A
100-pin differential probe E5379A
38-pin single-ended probe E5380A
Single-ended flying lead probe set E5382A
Differential flying lead probe set E5381A
