Chapter 2: Preparing for Use
Power Requirements
All power supplies required for operating the logic analyzer are supplied through
the backplane connector in the mainframe.
Operating Environment
The operating environment is listed on page 13. Note the non-condensing
humidity limitation. Condensation within the instrument can cause poor
operation or malfunction. Provide protection against internal condensation.
The logic analyzer module will operate at all specifications within the
temperature and humidity range given on
page 13. However, reliability is
enhanced when operating the module within the following ranges:
Temperature: +20°C to +35°C (+68°F to +95°F)
Humidity: 20% to 80% non-condensing
Storage
Store or ship the logic analyzer in environments within the following limits:
• Temperature: -40°C to +75°C (-40°F to +167°F)
• Humidity: Up to 90% at 65°C (+149°F)
• Altitude: Up to 15,300 meters (50,000 feet)
Protect the module from temperature extremes which cause condensation on the
instrument.
To inspect the module
1 Inspect the shipping container for damage.
If the shipping container or cushioning material is damaged, keep them until you
have checked the contents of the shipment and checked the instrument
mechanically and electrically.
2 Check the supplied accessories.
One or more of the accessories listed on page 10 are required to operate the
16753/54/55/56A or 167950A logic analyzer module.
3 Inspect the product for physical damage.
Check the module and the supplied accessories for obvious physical or
