12
Chapter 1: General Information
Characteristics
The characteristics are not specifications, but are included as additional
information.
Full-Channel Mode Half-Channel Mode
Maximum Conventional Timing Rate 600 MHz 1.2 GHz
Sample Rate, Timing Zoom 4 GHz 4 GHz
Channel Count per Card 68 34
Channel Count per Three-Card Module 204 102
Channel Count per Five-Card Module 340 170
Memory Depth 16753A 1 M Samples 2 M Samples
Memory Depth 16754A 4 M Samples 8 M Samples
Memory Depth 16755A 16 M Samples 32 M Samples
Memory Depth 16756A 64 M Samples 128 M Samples
Memory Depth 16950A Option 256 256 K Samples 512 K Samples
Memory Depth 16950A Option 001 1 M Samples 2 M Samples
Memory Depth 16950A Option 004 4 M Samples 8 M Samples
Memory Depth 16950A Option 016 16 M Samples 32 M Samples
Memory Depth 16950A Option 032 64 M Samples 128 M Samples
Memory Depth 16950A Option 064 1 M Samples 512 K Samples
