124
Chapter 7: Replaceable Parts
Replaceable Parts
Ref. Des. Agilent Part Number QTY Description
Exchange Assemblies
16753-69510
16754-69510
16755-69510
16756-69510
16950-69510
Exchange Acquisition Board Assembly
Replacement Assemblies
A1 16753-66510
16754-66510
16755-66510
16756-66510
16950-66510
1
Acquisition Board Assembly
16760-60001 0 Stimulus Board Assembly (for cable test;
see
page 104 or page 99)
H1 16903-68713 2 Replacement thumb screws with sleeve,
2 sets
H1 16900-68713 2 Replacement thumb screws with sleeve,
6 sets
H2 16754-29101 1 Ground Spring
H3 0515-0375 8 M3.0x0.5 16mm T10 (Cable Clamp to
Acquisition Board)
H4 0515-0430 3 MSPH M3.0x0.50 6mm T10 (Rear Panel to
Acquisition Board)
01650-94312 1 Label - Probe and Cable (on 90-pin
connector)
MP1 16754-44101 1 Rear Panel
MP2 16754-41201 2 Logic Analyzer Cable Clamp
MP3 16753-94301
16754-94301
16755-94301
16756-94301
16950-94301
1 ID Label
W1 16754-61602 1 2x15 Cable
W2 16754-60002 1 2x50 Master/Expander Cable Kit (2 pieces)
W3 16760-61605 4 Logic Analyzer Cable
