Agilent 16753/54/55/56A and 16950A Logic Analyzers—At a
Glance
The 16753A, 16754A, 16755A, and 16756A are 600 MHz logic analyzer modules
for the 16700-series or 16900-series logic analysis system.
The 16950A is 600 MHz logic analyzer module for the 16900-series logic analysis
system.
The 16753/54/55/56A and 16950A logic analyzer modules offer high performance
measurement capability.
Features
Some of the main features of the 16753/54/55/56A and 16950A are as follows:
• 64 data channels
• 4 clock/data channels
• 1 M to 64 M memory depth per channel (depends upon model or option chosen)
• 600 MHz maximum state acquisition speed
• 1.2 GHz, 128 M deep timing analysis on half channels
• “Eye scan” feature
• 4 GHz timing zoom with 64 k memory depth
• Expandable to 340 channels
Service Strategy
The service strategy for this instrument is the replacement of defective
assemblies. This service guide contains information for finding a defective
assembly by testing and servicing the 16753/54/55/56A or 16950A state and
timing analyzer module.
The modules can be returned to Agilent Technologies for all service work,
including troubleshooting. Contact your nearest Agilent Technologies Sales
Office for more details.
