Agilent Technologies 34980A User Manual

Microwave Switch/Attenuator Driver 8
34980A User’s Guide 247
87222 Cable
9 Conductor Cable
Y1154A Switch Control
All channels are operated in PAIRed mode.
Item Description Example Part Numbers
Cable Type 10 conductor ribbon cable, 0.050" pitch, 26 or
28 AWG stranded
3M 3801/10 (26 AWG)
3M 3365/10 (28 AWG)
Y1154A Connector 14 pin socket connector, 0.1" x 0.1" pin grid,
IDC termination, center polarizing key
3M P/N 89114-0101
AMP P/N 76288-2
Switch Connector 10 pin socket connector, 0.1" x 0.1" pin grid,
IDC termination, center polarizing key
3M P/N 89110-0101
AMP P/N 76288-1
Cable Wiring Y1154A connector pin 1 to switch connector
pin 1 (Note: pins 11 - 14 of 14 pin connector not
used)
Item Description Example Part Numbers
Cable Type 9 conductor ribbon cable, 0.050" pitch, 26 or
28 AWG stranded
3M 3801/09 (26 AWG)
3M 3365/09 (28 AWG)
Y1154A Connector 10 pin socket connector, 0.1" x 0.1" pin grid,
IDC termination, center polarizing key
3M P/N 89110-0101
AMP P/N 76288-1
Switch Connector 9 pin D-sub male, IDC termination, without
threaded insert
3M P/N 8209-6000
AMP P/N 747306-4
Cable Wiring Y1154A socket connector pin 1 to switch
D-sub connector pin 1
(Note: pin 10 of Y1154A connector not used)
State A State B
SW1 ROUT:OPEN (@xx01) ROUT:CLOS (@xx01)
SW2 ROUT:OPEN (@xx02) ROUT:CLOS (@xx02)
SW3 ROUT:OPEN (@xx03) ROUT:CLOS (@xx03)
SW4 ROUT:OPEN (@xx04) ROUT:CLOS (@xx04)
SW5 ROUT:OPEN (@xx05) ROUT:CLOS (@xx05)
SW6 ROUT:OPEN (@xx06) ROUT:CLOS (@xx06)
SW7 ROUT:OPEN (@xx07) ROUT:CLOS (@xx07)
SW8 ROUT:OPEN (@xx08) ROUT:CLOS (@xx08)
