244 34980A User’s Guide
8 Microwave Switch/Attenuator Driver
Y1154A
The Y1154A supports one of the transfer switches listed below and up to
six N181x switches.
Y1154A Switch Options Supported
(Recommended options are shaded).
Agilent Switch Description
87222C/D/E 4 port transfer switch
N1810UL Unterminated latching 3-port (SPDT)
N1810TL Terminated latching 3-port (SPDT)
N1811TL Terminated latching 4-port (transfer)
N1812UL Unterminated latching 5-port
Option Name Option Number Description and Comments
Frequency Range letter suffix in
model number
All options supported
Coil Voltage STD (no options) +24VDC nominal (+20VDC to +32VDC allowed)
DC Connector Type
STD 10 pin ribbon cable header
100 Solder lugs
Can use ribbon cables with the Y1154A,
or discrete wires with the Y1155A.
Mounting Bracket 201 All options supported
Calibration Certificate UK6 All options supported
Drive Options STD Direct coil connections for open collector drive
and TTL/5V CMOS compatible inputs standard
