34933T-001 Terminal Block for Two-Wire Mode
This terminal block with screw- type connections is labeled with the
model number and the abbreviated module name. In addition, space is
available on the label for you to write the slot number.
The 34980A Product Reference CD (shipped with the instrument)
contains a 34933T (2- wire) Wiring Log for you to document your wiring
configuration for this module. You can open the wiring log file in
Microsoft® Excel® or Adobe® Acrobat® format
NOTE
All modules that connect to the internal DMM are interlock
protected. This means that when an installed module is exposed (no
terminal block or cable is connected), the Analog Bus relays, which
are on Matrix 2, are open and disconnected from the Analog Buses.
See page 162 for further information.
NOTE
If you are using an Agilent terminal block to connect your DUT to
this module be sure to use the 34933T-001 terminal block that
corresponds to the 2-wire configuration mode. Note that an error
will not be generated if you have installed a terminal block that
doesn't match the present module configuration.
