Agilent Technologies 34980A User Manual

Microwave Switch/Attenuator Driver 8
34980A User’s Guide 249
Y1155A
The Y1155A provides screw terminal connections can support the Agilent
switches listed below. Additionally, the screw terminals make it adaptable
to most any switch.
Agilent Switch Description
8762A/B/C Terminated latching 3-port (SPDT)
8762F 75 ohm terminated SPDT
8763A/B/C Terminated latching 4-port (transfer)
8764A/B/C Terminated latching 5-port
Other Switches Numerous
NOTE
When using the Y1155A, the ROUTe:RMODule:BANK:PRESet
command’s default configuration (see page 223) may not be suitable for
the wide variety of switches and devices available. You will need to
manually configure the channel drive attributes to ensure safe reset
operations of these switch systems.
