Agilent Technologies 35670A - Page 155

Frequency Accuracy
Measurement Lower
Limit
(kHz)
Upper Limit
(kHz)
Measured Value
(kHz)
Pass/Fail
50 kHz 49.9985 50.0015
Single Ch Phase Accuracy
Measurement Lower
Limit
(deg)
Upper Limit
(deg)
Measured Value
(deg)
Pass/Fail
Positive slope, Ch 1 -4 4
Positive slope, Ch 2 -4 4
Negative slope, Ch 1 -4 4
Negative slope, Ch 2 -4 4
ICP Supply
Measurement Lower
Limit
Upper Limit Measured Value Pass/Fail
Ch 1 Open Circuit Voltage 26 Vdc 32 Vdc Vdc
Ch 2 Open Circuit Voltage 26 Vdc 32 Vdc Vdc
Ch 1 Current 2.75 mA 5.75 mA mA
Ch 2 Current 2.75 mA 5.75 mA mA
Serial Number:_______________________Report Number:____________________
Test Date:___/___/___
Agilent 35670A Verifying Specifications
Operation Verification Test Record - Two Channel
9 of 10
