6 General Maintenance

To Clean an EI XTR, SS, or Inert Source

182 5977C GC/MSD Operating Manual

3 Collect the following parts to be cleaned for an EI XTR source: (See Figure 59

on page 183.)

• Repeller

• Repeller block insert

• Source body

• Extractor lens

• Ion focus lens

• Entrance lens

These are the parts that contact the sample or ion beam. The other parts

normally should not require cleaning.

CAUTION

If insulators are dirty, clean them with a cotton swab dampened with

reagent-grade methanol. If that does not clean the insulators, replace them. Do

not abrasively or ultrasonically clean the insulators.
