2 Installing 8890 GC Columns
To Install a Capillary Column in a Split/Splitless Inlet
38 5977C GC/MSD Operating Manual
To Install a Capillary Column in a
Split/Splitless Inlet
Materials needed
• Gloves, clean
• Large (8650-0030)
• Small (8650-0029)
• Metric ruler
• Wrench, open-end, 1/4-inch and 5/16-inch (8710-0510)
• Capillary column
• Column cutter, ceramic (5181-8836) or diamond (5183-4620)
• Ferrules
• 0.27-mm id, for 0.10-mm id columns (5062-3518)
• 0.37-mm id, for 0.20-mm id columns (5062-3516)
• 0.40-mm id, for 0.25-mm id columns (5181-3323)
• 0.5-mm id, for 0.32-mm id columns (5062-3514)
• 0.8-mm id, for 0.53-mm id columns (5062-3512)
• Inlet column nut (5181-8830 for Agilent 9000 or 8890 GCs)
• Magnifying loupe
• Septum (may be old, used inlet septum)
To install columns in other types of inlets, refer to your GC User Information.
The GC operates at high temperatures. Do not touch any parts of the GC until
you are sure they are cool.
Always wear safety glasses when handling capillary columns. Avoid
puncturing your skin with the end of the column.
Always wear clean gloves while handling any parts that go inside the GC or
analyzer chambers.
