4 Operating in EI Mode

Front Panel Instrument Status LED

84 5977C GC/MSD Operating Manual

Front Panel Instrument Status LED

Through the front panel instrument status LED, the operator can view the current

status of the instrument using color codes and LED on/off timing. (See Table 7.)

Table 7 Front panel Instrument Status LED codes

Instrument status LED code

Ready Solid green

Acquiring data Blinking green (<2 sec)

Not ready Solid yellow

JetClean Acquire & Clean operation Blinking magenta

JetClean Clean Only operation Solid magenta

Ready and not connected to DS Solid blue

Start up (prior to FW load) Blinking red (<2 sec)

Fault Solid red
