7CI Maintenance

To Connect/Disconnect Wiring to the EI HES Radiator

208 5977C GC/MSD Operating Manual

Figure 68 Wiring between the ceramic source board/feedthrough connector and the EI HES radiator

* The number in parenthesis is the

number engraved on the lens.

Entrance lens (1)*

Ion focus lens (2)*

Post extractor lens 2 (3)*

Post extractor lens 1 (4)*

Extractor lens (5)*

Ground wire

Heater wires

RTD wires

Ceramic source board
