Agilent 708-DS Dissolution Apparatus
Training Manual
Revision A September 2010
P/N: xx-xxxx
Beyond the scope of compendial devices, other vessel sizes and drug delivery
mechanisms may be used with the 708-DS. These include 200, and 2000mL
vessels sizes complete with appropriately scaled accessories. Also, stationary
baskets and enhancer cells may be configured.
The apparatus itself has many different configuration possibilities. The 708-DS
is available with a manual or automated lift mechanism to control the drive unit.
Other additional options include: AutoTemp, Auto Sampling, Dosage Delivery
Modules (DDM) and a Printer. Each of these will be explained in greater detail
throughout this manual.
1.2. The Firmware
Setup and operation of the instrument is controlled via the LCD touch screen
on the front of the unit. The Main screen, displayed after initialization occurs,
provides the current status of several instrument parameters as well as a
variety of “hotspots” and buttons to initiate operation.
Figure 1-2. Main Screen
Press the ‘Menu...’ button from the Main screen to display the primary System
Menu. From this screen, the user has the ability to configure the apparatus to
their exact specifications. These options include method setup, instrument
settings, diagnostic tests, and more.
1.3. Optional Configurations
As mentioned previously, the apparatus has an assortment of configurable
options. While many of these are selected at the time of ordering, most may be
added at a later time if and when laboratory testing needs change.
A manual or automated Head Lift mechanism is used to raise and lower the
apparatus’ drive unit.
