Agilent Technologies 7697A Troubleshooting

Leaks 4
Agilent 7697A Troubleshooting 55
Cross port leak test, stage 1: Test 6PORT (STANDBY)
During this stage, the HS flow paths are as shown in
Figure 10:
Figure 10 Flow paths: Cross port leak test, stage 1: Test 6PORT
(STANDBY)
SV1
PV2
Flow control module
1
2
3
4
5
6
Transfer
line
Vent
Carrier gas
Vial pressurization
gas
PS - Pressure sensor
FS - Flow sensor
SV - Switching valve
PV - Proportional valve
PV1
PS
FS
SV2
PS
Six port valve
Sample loop
