5-27
Supplement for the Reference Guide (Firmware Revision 7.68)
Options and Accessories
Options and Accessories
Accessories Available
Added new calibration kits and updated Electronic calibration (ECal) section.
Calibration Kits
Choose a kit for each connector type to be used.
• 85032F 50 Ω type-N calibration kit (30 kHz to 9 GHz)
Contains a female and male open and short, female and male load standard, and a
torque wrench.
— Option 500
Adds four type-N to 7-mm adapter.
• 85033E 50 Ω 3.5-mm calibration kit (30kHz to 9 GHz)
Contains a female and male open and short, female and male load standard, and a
torque wrench.
— Option 400
Adds four 3.5 mm to Type-N adapters.
— Option 500
Adds four 3.5 mm to 7-mm adapters.
RF electronic calibration (ECal) modules and PC software
This product family provides electronic calibration (ECal) capability. With ECal, the usual
calibration kit standards are replaced by one solid-state calibration module. A full two-port
calibration can be done with a single connection, with reduced errors and wear on
connectors. ECal requires the 85097A PC interface kit, an 85090-series calibration module
with the appropriate connector type, and a network analyzer with firmware version 7.68
and above.
NOTE For network analyzers with firmware versions between 7.60 and 7.68, a PC
with Windows
1
95, 98, 2000 or NT 4.0 loaded with software from the
85097A PC interface kit is used to perform the ECal calibration.
• 85097A ECal PC interface kit and software
— Contains PC interface module for connecting an ECal module to a PC or a network
analyzer (with firmware version 7.68 and above) and PC ECal control software.
• 85091B RF ECal module (30 kHz to 9 GHz), 7-mm connectors
• 85092B RF ECal module (30 kHz to 9 GHz), 50 Ω type-N (m) to 50 Ω type-N (f)
connectors
1. Windows is a U.S. registered trademark of Microsoft Corporation.
