1 Agilent 8860 GC Site Preparation
Maximum Length of Cables and Hoses
10 Site Preparation Guide
Maximum Length of Cables and Hoses
The distance between system modules may be limited by some of the cabling and the vent or
vacuum hoses.
The supporting surface for the 7200/7250 Q-TOF GC/MS system should be kept relatively
vibration free. Do not put the rough pump on your laboratory bench with the 7200/7250
Q-TOF GC/MS due to the vibration that the pump creates. Vibration can lead to a loss of
mass accuracy and resolution.
Table 1 Cable and hose lengths
Item Length
Remote cable 2 m (6.6 ft)
LAN cable 10 m (32.8 ft)
Power cords 2 m (6.6 ft)
Vacuum hose 1.3 m (4.24 ft)
Foreline pump power cord 2 m (6.6 ft)
7697A Headspace Sampler transfer line 99 cm (39-in.)
G1888 Headspace Sampler transfer line 80 cm (31.5-in.)
