2 GC Installation Kits
Installation Kits
14 Site Preparation Guide
Installation Kits
Installation kits are not supplied with the GC. If you did not order the GC with the factory
plumbing option (305), Agilent highly recommends the following kits in Table 2.
• Agilent recommends purchasing the installation kit(s) that provides parts useful for GC
installation. (Table 2 lists the appropriate installation kits.)
In addition to these installation kits, fittings and reducers are required to convert gas cylinder
regulator fittings (for example, 1/4-inch male NPT) to the 1/8-inch female Swagelok fittings
needed to connect gases to the instrument. These fittings are not included with the GC or with
the installation kits. See “Gas Plumbing” on page 49 for details.
Table 2 Installation kits
Kit Part number Contents
Recommended for GCs with FID, NPD, FPD:
GC Supply Gas Installation
Kit with Gas Purifiers
See Figure 1.
19199N Includes Gas Clean Filter system kit
CP736530 (with 1 oxygen, 1 moisture,
and 2 charcoal filters), 1/8-inch brass
nuts and ferrules, copper tubing,
1/8-inch brass tees, tubing cutter,
1/8-inch brass caps, universal external
split vent trap with replacement
cartridges, and 1/8-inch ball valve.
Recommended for GCs with TCD/ECD, MS, and MSD:
GC Supply Gas Installation
Kit
See Figure 2.
19199M Includes 1/8-inch brass nuts and
ferrules (20), copper tubing, 1/8-inch
brass tees, tubing cutter, 1/8-inch brass
caps, 7-mm nut driver, T-10 Torx driver,
T-20 Torx driver, 4 open-end wrenches,
and 1/8-inch ball valve
Gas Clean carrier gas filter
kit, 1/8-inch
See Figure 3.
CP17974
