Agilent Technologies 8860 Site Preparation Guide

3 Dimensions and Weights
Dimensions and Weight
18 Site Preparation Guide
Dimensions and Weight
1 Ensure that you can accommodate the shipping pallets when you take delivery.
See Table 3.
2 Prepare laboratory bench space before the system arrives. Make sure the prepared area is
clean, clear, and level. Pay special attention to the total height requirements. Avoid bench
space with overhanging shelves. See Table 4.
Table 3 Pallet dimensions and weights
Product Height Width Depth Weight
GC
8860 Series GC shipping pallet
With third side detector (side mount)
76 cm (30-inch)
76 cm (30-inch)
86 cm (34-inch)
87 cm (34-inch)
103 cm (40.5-inch)
108 cm (42.5-inch)
N/A
MS
7200/7250 Q-TOF MS 96 cm (38-inch) 130 cm (51-inch) 91 cm (36-inch) 175 kg (385 lb)
7200 Flight Tube 66 cm (26-inch) 66 cm (26-inch) 147 cm (58-inch) 36.4 kg (80 lb)
7250 Flight Tube 66 cm (26-inch) 206 cm (81-inch) 81 cm (32-inch) 87 kg (191 lb)
Table 4 Instrument dimensions, weights, and required clearances
Product Height Width Depth Weight
GC
8860 Series GC
With third side detector (side mount)
50 cm (19.2-inch)
50 cm (19.2-inch)
59 cm (23-inch)
68 cm (27-inch)
54 cm (21-inch)
54 cm (21-inch)
50 kg (112 lb)
57 kg (125.4 lb)
• GC operational /oven access Requires
≥ 30 cm (12-inch) open space above GC.
Requires
≥ 27 cm (10.7-inch) open space in front of GC.
• GC rear ventilation / maintenance
clearance
Requires
≥ 25 cm (10-inch) clearance between back of instrument and
wall to dissipate hot air and allow for routine maintenance.
MSD
5975 Series MSD
• Diffusion pump 41 cm (16-inch) 30 cm (12-inch) 54 cm (22-inch) 39 kg (85 lb)
• Standard turbo pump 41 cm (16-inch) 30 cm (12-inch) 54 cm (22-inch) 39 kg (85 lb)
• Foreline pump
Standard
Oil-free
21 cm (8-inch)
19 cm (7.5-inch)
13 cm (5-inch)
32 cm (13-inch)
31 cm (12-inch)
28 cm (11-inch)
11 kg (23.1 lb)
16 kg (35.2 lb)
• GC/MS operational and maintenance
access
Requires 30 cm (1 ft) to the left of the unit.
5977 Series MSD
• Diffusion pump 41 cm (16-inch) 30 cm (12-inch) 54 cm (22-inch) 39 kg (85 lb)
• Performance turbo pump 41 cm (16-inch) 30 cm (12-inch) 54 cm (22-inch) 41 kg (90 lb)
