324 Chapter 5
Programming Fundamentals
Using the LAN to Control the Instrument
Programming Fundamentals
General LAN Troubleshooting
• “Troubleshooting the Initial Connection” on page 5-324
• “Common Problems After a Connection is Made” on page 5-326
• “Pinging the Instrument from a Computer or Workstation” on
page 5-328
• “EIA/TIA 568B Wiring Information” on page 5-330
Troubleshooting the Initial Connection
Getting the instrument to work with your network often requires
detailed knowledge of your local network software. This section
attempts to help you with some common problems. Contact your
network administrator for additional assistance.
The instrument LAN interface does not need or include any proprietary
driver software. It was designed to operate with common network
utilities and drivers.
Either a hardware problem or a software problem can prevent the
instrument's remote file server from communicating over the LAN. The
following common problems may be encountered:
Communications Not Established If you have just installed and
configured the LAN interface and you have never been able to access
the instrument via ftp or telnet, go directly to “Pinging the
Instrument from a Computer or Workstation” on page 5-328.
If you have previously been able to access the instrument via ftp or
telnet and now cannot do so, check the following:
o Has any hardware been added or moved on your network? This
includes adding or removing any workstations or peripherals, or
changing any cabling.
o Have software applications been added to the network?
o Has the functionality been turned off from the front panel? Press
System, Config I/O, SCPI LAN.
o Have any configuration files been modified? Pressing System,
Restore Sys Defaults
restores the original factory defaults and you
will have to re-set the instrument IP address and host name.
o Is the upper- and lower-case character usage in your host name
consistent?
