Agilent 1260 Infinity II Preparative Autosampler User Manual 65
Installation of the Optional Sample Cooler
4
Using the Sample Cooler in an Infinity II Sampler
Using the Sample Cooler in an Infinity II Sampler
The following section describes exemplarily how to use the sample cooler in
the multisampler. The principle is the same for other sampler types.
After successfully loading the Agilent CDS, the module should appear as an
active item in the graphical user interface (GUI).
Within the autosampler GUI, there are active areas. If the mouse cursor is
moved across the icons the cursor will change, see the following figure.
ALS configuration is displayed when moving with the mouse cursor over the
syringe. The information provides ALS related information like
• Part number
• ALS setup
and other details.
1 ALS: turn on and off
2 ALS configuration
3ALS Status
4 Chiller Status (on/off)
5Injection Volume
6 Drawer Configuration
7EMF Status
