Agilent 1260 Infinity II Preparative Autosampler User Manual 87
Preparing the Module
5
Setting up the Sampler
Setting up the Sampler
The setup of the sampler is shown exemplarily for the Vialsampler.
Table 7 The Vialsampler User Interface
Within the Vialsampler user interface, there are active
areas. If you move the mouse cursor across the icons (tray,
EMF button), the cursor will change and you may click on
the icon to
1
Turn on /off the Vi als ampler
2
Check which sample drawers are installed
3
Get the status of the EMF (Early Maintenance Feature)
4
Cooling Temperatur (if sample cooler is installed)
Current instrument information on:
• Injection volume
•Sample location
A right-click into the Active Area will open a menu with
the option to adjust the following parameters:
• Show the Control User Interface (special module
settings). See “Control Settings” on page 90.
• Show the Method User interface (same as via menu
Instrument > Set up Instrument Method > Setup
G7129B). See “Method Parameter Settings” on
page 91.
• Injector Program
When you activate a pretreatment/injector program, it
replaces the standard injection cycle. See “Using an
Injector Program” on page 100
• Identify Device
•Home Arm
• Reset Injector
• Release Vial
•Switch Valve to Bypass
• Switch on Tray Illumination
• Needle Wash: allows you to wash the needle without
modifying your current method. The needle wash
specified in this dialog box is carried out immediately.
• Modify
• Flow Path
• External Tray
• Temperature Mode
