Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Replaceable Parts
Assemblies and Hardware Options
2-27
Outer Instrument Cover and Associated Parts
Table 2-10Outer Instrument Cover and Associated Parts
Item No. Description Qty Part Number
1 Assy-Strap Handle - includes the following parts: 1 E4400-60026
Strap Assembly 1
Ground Spring 2
Handle Retainer 2
End Cap 2
Screw-Machine M5 x 18 FL-TX 2
2 Hole Plug (not shown in photo) 2 W1312-40024
3 Screw-Machine M5 x 0.8 12mm-lg (not shown in photo) 2 0515-0708
4 Rear Feet Screws (not shown in photo) 4 0515-1619
5 Rear-Panel Feet 4 5041-9611
6 Feet-Bottom 1 5041-9167
7 Tilt Stand 1 1460-1345
8 Set of 4 Bottom Feet with Tilt Stands (not shown in photo) 1 5000-0913
9 Outside Instrument Cover 1 W1312-00018
10 Hole Plug, Bottom Feet (not shown in photo) 1 W1312-40032
11 Front Panel Cover 1 N5180-40012
