Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Assembly Replacement
Outer Cover
3-4
Outer Cover
Tools Required
• T-20 driver
Removal Procedure
Refer to Figure 3-1 for this procedure.
1. Disconnect the power cord.
2. Using the T-20 driver, loosen the two screws (1) and remove the strap handle (2).
3. Using the T-20 driver, remove the two hole plugs (not shown in photo) from the opposite side of the instrument.
4. Using the T-20 driver, remove the center screws from the four rear-panel feet (3).
5. Remove the four bottom feet (4) from the cover by lifting the tab and sliding the foot toward the tab.
6. Place the signal generator on its side.
7. Place one hand on the front panel, use the other hand to lift the rear of the signal generator and slide the outer cover (5) off to remove it
from the frame.
CAUTION The RF connector can be easily damaged. Use extreme caution to not damage the RF connector when lifting the rear of the
signal generator.
Replacement Procedure
1. Reverse the order of the removal procedures.
CAUTION When sliding the outer cover back on the signal generator keep fingers away from the back of the front panel. They can get
pinched.
2. Torque all screws to 21 in–lbs.
