Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Assembly Replacement
A8 Floating BNC Bypass (N5183A only)
3-62
A8 Floating BNC Bypass (N5183A only)
Tools Required
• 5/8” hex-nut driver
• needle-nose pliers
Removal Procedure
Refer to Figure 3-35 for this procedure.
1. Disconnect the power cord.
2. Remove the inner cover and outer top cover from the signal generator. Refer to ”Outer Cover” on page 3-4, ”Inner Top Cover” on
page 3-6.
3. Disconnect W15 from A7J14.
4. Using the 5/8” hex-nut driver, remove the nut and washer securing the A8 Floating BNC Bypass to the rear panel.
5. Remove the A8 Floating BNC Bypass.
Replacement Procedure
1. Reverse the order of the removal procedure.
2. Torque all screws to 9 in–lbs.
3. Perform the post-repair performance tests that pertain to this replacement procedure, see Chapter 4, Post-Repair Procedures and
Performance Verification.
