Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Troubleshooting
Getting Started with Troubleshooting
1-13
Getting Started with Troubleshooting
WARNING Immediately unplug the signal generator from the ac power line if the signal generator shows any of the following
symptoms:
• smoke, arcing, or unusual noise from inside the signal generator
• a circuit breaker or fuse on the main ac power line opens
If this rare symptom occurs it’s a potentially hazardous condition. Do not try to repair, instead, return the signal
generator to Agilent Technologies.
CAUTION For the instrument to meet performance specifications and for accurate self-test results, allow a warm up period of 45 minutes
within an operational temperature range of 0 to 55 °C. For more information, refer to the MXG signal generator Data Sheet.
This section describes the basic procedural flow of troubleshooting when servicing the N5161A, N5162A, N5181A, N5182A, or N5183A.
The following table provides a troubleshooting path from a failure symptom to the isolation of the possible fault. Perform troubleshooting in
the order presented in this table.
If able to run self test... Go to this section...
Run Self Test page 1-16
If unable to run self test or all self tests pass but the problem still exists, check... Go to this page...
Boot Time Diagnostic Mode (MXG ATE N5161A/62A) page 1-62
Exceptions - Auto-reboot, ERROR LED Blinking (MXG ATE N5161A/62A) page 1-63
Boot-Up Routine page 1-20
LCD Display Appears to be Inoperative (Dark) (N518xA only) page 1-52
Front Panel Appears to be Inoperative (N516xA only) page 1-38
If other conditions occur... Go to this page...
No Output Power or Output Power is Unleveled (N51
83A)
page 1-40
ALC Operation (N51
83A)
page 1-48
Amplitude Modulation Problems page 1-50
Pulse Modulation Problems page 1-51
The Instrument Does Not Power-On page 1-52
Front Panel LEDs are not Functioning page 1-56
The Green Front Panel Power Switch LED or Yellow Stand-by LED is not
Working
page 1-57
Front Panel Hardkey and Softkeys are not Functioning page 1-60
The RPG Knob is Not Functioning page 1-60
Blank or Missing Pixels page 1-62
The Screen Saver is Not Functioning page 1-62
Fans Do Not Turn On page 1-64
No Lan Activity page 1-64
No Front Panel USB Activity page 1-64
No Rear Panel USB Activity page 1-64
