Agilent N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide

Assembly Replacement

A7 Micro-Deck (N5183A only - Standard)

3-57

Figure 3-31A7 Micro Deck (N5183A only - Standard)

W15

W14

2.4mm - W9

3.5mm - W10

Type-N - W11

W13

W12
