Agilent Technologies N5161A/62A/81A/82A/83A MXG Signal Generators Service Guide
Post-Repair Procedures and Performance Verification
Post Repair Procedures
4-5
If a manual performance verification test fails:
1. Verify that the test setup is correct.
• For I/Q Calibration and Self Tests
— Confirm that all external cables, including GPIB, LAN, and USB cables, are disconnected from the signal generator.
• For Relative Frequency Range and Accuracy Verification
— Verify that the cables are connected correctly.
— Verify that the spectrum analyzer is set to external reference.
• For Leveled Output Accuracy Verification
— Verify you are using the appropriate power sensor.
— Normally, power sensor calibration factors are automatically downloaded to the power meter when the power meter turns on. If
this does not occur, manually enter the correct calibration factors for the power sensor you are using.
— Verify the power sensor is properly calibrated to the power meter.
2. If the tests setups are correct, go to “Troubleshooting Performance Test Problems” on page 1-72.
Table 4-3 Manual Performance Tests
Manuals Performance Tests
The following performance verification tests are listed in
the order that they should be performed.
Replaced Assembly
Key Pad
LCD Display
DC-AC Inverter Interface
A1 Power Supply
A2 Vector Module (N5162A/82A only)
A3 RF Assembly
A3 RF Assembly (N5183A only)
A4 Memory Chip (N5162A/82A only)
A5 CPU
I/Q Calibration (N5162A/82A only)
? ?
Self Tests
?????? ??
Relative Frequency Range and Accuracy Verification
? ?
Leveled Output Power Verification
??
0Phase Noise (N5183A only)
a
a
The phase noise test procedure is available as part of the N5183A calibration software.
?
