Source Key and Programming Commands
External Source Configuration
46
Source Key and Programming
Commands
4.1 External Source Configuration
Figure 4-1 Show Setup Screen
Figure 4-2 Spectrum Analyzer and Signal Source Connections
EXTERNAL
SOURCE
Product Number : <Model Number>
Serial Number: <Serial Number>
Start Frequency: <Start Frequency>
Stop Frequency: <Stop Frequency>
IP Address : <IP Address>
Show Setup
Show Setup
Spectrum
Analyzer
Swept Signal
Source
Trigger
Ext Frequency Reference
Sweep
LAN
sa_ss_connect.vsd
Trigger Out
(rear panel)
Trigger In
(rear panel)
Sweep Out
(rear panel)
Ext Trigger In
(front panel)
Signal Source drives the sweep of each PSA bucket
Drives the start of the PSA sweep
10 MHz Out
(rear panel)
Ext Ref In
(rear panel)
50 ohm feedthrough
MUST be connected at the PSA
end of the cable
