TriScroll 600 Dry Scroll Vacuum Pump

D R A F T 4 / 2 9 / 0 4

Callout Part Number Description

Quantity

PTS06101-UNIV and

PTS06103-UNIV

PTS06001UNIV and

PTS06003UNIV

NSS* Snap Ring N5000-75 1 1

S4835001 VDS20- Check Valve Plug 1 1

MK* O-ring, Viton 2-113 2 2

S4837001 VDS20- Check Valve Spacer 1 1

S4723002 VDS20- Check Valve 2 3

660285574 Spring, S/S, .18 OD x .75 L x .014 Wire OD 2 3

S4820001 VDS20- Plunger Guide 2 3

660285540 Spring, S/S, .72 OD x .75 L x .055 Wire OD 1 1

NSS* VDS20- Inboard Housing 1 1

NSS* Dowel Pin, Steel, M6x16 2 2

660285545 Spring, S/S, .72 x 2.00 L x .055 Wire OD - 1

S4806001 VDS20- Exhaust Fitting 1 1

MK* O-ring, Viton 2-207 1 1

NSS* Snap Ring, N5000-93 1 1

MK* Shaft Seal, 32mm x 42mm x 4mm 2 2

NSS* VDS20- Crankshaft Assembly 1 1

S4727001 VDS4- Seal Spacer 1 1

MK* O-ring, Viton 2-152 1 1

S4712001 VDS4- Seal Housing 1 1

NSS* Screw, Socket Head Cap, M5x10,

Black Steel

3 3

NSS* VDS20- Fan Assembly 1 1

NSS* Washer, 11/32 x 3/4 x 1/8 1 1

NSS* Screw, Socket Head Cap, M8x12,

Black Steel

1 1

MK* O-ring, Viton 2-140 1 1

MK = Included in major maintenance kit

TSK = Included in tip seal kit

NSS = Not sold separately
