TriScroll 600 Dry Scroll Vacuum Pump
D R A F T 4 / 7 / 1 1
Final Assembly
Tools required:
❑ Allen wrench
Locate the following items:
➀ Inboard housing assembly
➁ Spider coupling
➂ M6x16 screws (4)
1
2
3
