Agilent Technologies TriScroll 600 Series Major Maintenance Manual

52
TriScroll 600 Dry Scroll Vacuum Pump
D R A F T 4 / 2 9 / 0 4
Callout Part Number Description Quantity
MK* 7304WN SU Bearing 1
S4829001 VDS20- Orbiting Spacer 1
MK* VDS4- Nylon Sleeve 1
MK* J9104P x1527 Bearing 1
S4758001 Wave Washer - Nested 1
NSS* VDS20- Center Orbiting Plate 1
NSS* DIN472-0150 Snap Ring 3
MK* Shaft Seal, 8x15x3 3
MK* NK 8/12 Needle Bearing 3
MK* 2-016 Viton O-ring 6
NSS* M5x5 Set Screw 6
MK* Shaft Seal 22x30x4 1
S4816001 Steel Washer 1
S4857001 Wave Washer 1
MK = Included in major maintenance kit
TSK = Included in tip seal kit
NSS = Not sold separately
1
2
3
4
5
6
7
8
9
10
11
12
13
14
