Getting Started
Agilent Vapor Generation Accessory VGA 77 and VGA 77P User’s Guide 29
Installing the Burner Clamp
This section applies to AA modules only.
CAUTION
Do not use the cell with a nitrous oxide–acetylene burner. The cell will be
destroyed if exposed to a nitrous oxide-acetylene flame.
Mark 7 Burner
The VGA 77 is supplied with a cell holder for the Mark 7 burner. The
Mark 7 does not require mounting brackets as the cell holder simply
sits on top of the burner.
Figure 5. Mark 7 burner without holder
To mount the cell holder on the Mark 7 burner:
1 Position the seat cut-outs of the holder over the back edge of the
burner.
