3.1.1 MULTI-FUNCTIONAL JOYSTICK
Remember that all operations carried out with the joystick must be done with the
“hold to run” button held down for some operations.
Description of the buttons:
Button Function
1 + 13 Cutter reverse
2 + 13 Cutter loading – three modes that can be increased by pressing button 2
3 + 13 Open cutter protection grille
4 + 13 Close cutter protection grille
5 + 13 Open unloading door
6 + 13 Close unloading door
7 + 13 Turn on mixing auger / one click increase auger RPM
8 + 13 Double click turn off mixing auger / one click decrease auger RPM
9 + 13 Move unloading belt to the right
10 + 13 Move unloading belt to the left
11 + 13 Optional
12 + 13 Optional
The joystick for the cutter is
located behind the hand throttle.
