5.8 FUSES
To avoid serious damage to the electrical system, replace fuses using new fuses
with the same specifications.
re is a box located at the back of the driver’s cab that contains the fuses for the various
machine components (FIG.1).
FUSE BOX: X313 (FIG.1)
FUSE BOX: X314 (FIG.1)
MINI RELAY: X310 (FIG.1)
MICRO RELAY: X311 (FIG.1)
MINI RELAY: X312 (FIG.1)
ENGINE COMPARTMENT FUSES: LOCATED INSIDE THE ENGINE COMPARTMENT
AS YOU OPEN THE COVER ON THE LEFT (FIG.2)
FIG.2
FIG.1
