FUSE BOX X313 & X314
F12 F13 F15 F16
FUSE BOX X313
F1 WEIGHT 10 A
F2 4 TURN SIGNALS 10 A
F3 STARTER PANEL 10 A
F4 REAR WORK LIGHT 5 A
F5 FRONT WORK LIGHT 15 A
F6 FRONT WORK LIGHT 15 A
F7 HEATED MIRRORS 10 A
F8 SIDE LIGHTS 10 A
F9 LOW BEAM HEADLIGHTS 10 A
F10 KILL SWITCH POWER 15 A
F11 REAR FOG LIGHT 7.5 A
F12 OPTIONAL 10 A
F13 BACKUP BEEPER 7.5 A
F14 HIGH BEAMS 10 A
F15 J.D. DIAGNOST. TOOL 3 A
F16 + 30 STARTING 30 A
FUSE BOX X314
F1 SEAT MICROSWITCH 15 A
F2 FUEL LEVEL 3 A
F3 SENSORS 5 A
F4 JOYSTICK 5 A
F5 DISPLAY 10 A
F6 CONTROL UNIT C2 25 A
F7 CONTROL UNIT C1 25 A
F8 DANFOSS DIAGN. OUTL. 1 A
F9 WEIGHT 10 A
F10 TLB 10 A
F11 BRAKE LIGHTS 5 A
F12 PNEUM. SEAT 5 A
F13 ROTATING BEACON 15 A
F14 WARNING HORN 7.5 A
F15 REAR R+L PARK. LIGHTS 3 A
F16 FRONT R+L PARK. LIGHT 20 A
MINI RELAY X310
R1 R2 R3 R4
RELAY X310
R1 ROTATING BEACON
R2 RH WORK LIGHT
R3
R4 REAR RH WORK HOLE
