3.12 TOP-CUT COUNTER-KNIVES
The TOP-CUT system consists of a hydraulically-operated steel counter blade attached at the
perimeter of the mixing tank.
This system allows excellent cutting of fibrous products combined with the rotating action of
the auger.
Activating the TOP-CUT knives is controlled with button n° 2 on the control panel (FIG.1)
and they can be used in timed automatic or manual mode (A). In automatic mode, the
maximum cycle can be regulated with buttons n° 3 and 4 (B) (from 1 min. to 60 min.), the
IN time with buttons n° 5 and 6 (C) and the OUT time with buttons n° 7 and 8 (D). At the
end of the operation, press the “SAVE” button to save the settings
FIG.1
The selecting of these times depends on the type of fiber to be mixed.
Never start the auger with product inside the tank and with the TOP-CUT knives
inserted. There could be dangerous overloading of the auger motor.
