3.10 UNLOADING AND DISTRIBUTION
After the product is done being mixed, it can be distributed directly into the trough
using the controls on the joystick.
Draw near to the trough keeping the auger in motion.
If a discharge extension is present, press button n°11 (pg.19) to lower it.
Open the unloading door with button n°5+13 (pg.19) at a suitable height
according to the product type.
Start the unloading belt on the desired side with button n° 10+13 (pg.19) for
the left side and button n° 9+13 (pg.19) for the right side.
Increase the auger RPMs with button n° 7+13 (pg.19) so as to make the
material flow from the tank.
Start unloading, regulating the quantity of product desired in the trough.
When the unloading belt shuts off, the auger also shuts off automatically, and
vice versa.
When unloading is finished, stop the auger, close the door with button n°
6+13 (pg.19) and stop the unloading belt with button n° 10+13 (pg.19)
or button n° 9+13 (pg.19) for the right belt.
IT IS RECOMMENDED THAT PROCESSED PRODUCT NOT BE LEFT
INSIDE THE TANK.
3.11 CUTTING AND MIXING TANK
BE EXTREMELY CAREFUL when approaching the edge of the mixing tank with the
mixing augers in motion! DANGER OF DEATH!
The operator can see inside the cutting and mixing tank by climbing up to the
platform on the right side, with the machine stopped and on level ground.
The cutting-mixing auger in the MAXI is driven by pressing twice button n° 7+13 (pg.19)
at 5 RPM. To increase the number of revolutions, press button n° 7+13 (pg.19) (maximum
42 RPM). To decrease the RPMs, press button n° 8+13 (pg.19).
The auger RPMs are automatically restricted to 30g/min as soon as the system detects a
preset load value. During loading, as soon as the load falls below the threshold, the auger will
once more be able to reach 42g/min.
The auger knives are subject to wear, thus it is recommended that they be checked
periodically: if they are damaged or worn, contact qualified personnel for replacement with
original parts, or contact SITREX.
