3.13 TANK INSPECTION LADDER
DO NOT STAND ON THE PLATFORM WHILE
THE MACHINE IS IN OPERATION
3.14 OVERFLOW RING
The overflow ring is used for fodder loads, to avoid having the hay or straw pushed out of the
tank by the rotation of the vertical auger, especially with a load of bales.
DANGER: Do not try to climb on the overflow ring because there is the danger of falling into
the mixing tank where the auger and knives are found.
3.15 WATER SUPPLY PIPE
The pipe for supplying water (optional) is for those who need to wet dry products to avoid
creating dust during mixing, or simply for the convenience of being able to connect a pump
that draws water from a well, for example, to the lower edge of the tank, without having to
climb a ladder with a loose water hose.
There is a ladder with platform located on the front right
part of the machine for checking the mixing inside the
tank.
