MICRO RELAY X311
R1 R2 R3 R4 R5 R6 R7
RELAY X311
R1 REVERSE
R2 BRAKE LIGHT
R3 BACKUP BEEPER
R4 INTERMITTENCE
R5 LOW BEAM HEADLIGHTS L R
R6 HIGH BEAM HEADLIGHTS L R
R7 HORN
MINI RELAY: X312
R1 R2 R3 R4
RELAY X312
R1 REAR RH WORK LIGHT
R2 TURN ON FANS FROM D+
R3 START GEAR ENGAGED
R4 START KILL SWITCH
ENGINE COMPARTMENT FUSES
HOOD FUSES & RELAY
X156 FAN 1 OIL RADIATOR RELAY
X157 OPT POWER RELAY
X158 FAN 2 OIL RADIATOR RELAY
X159 FAN 1 OIL RADIATOR FUSE
X161 OPT POWER FUSE
X162 FAN 2 OIL RADIATOR FUSE
X 303 CAB MAXI FUSE 30A
X559 + 15 ACCESSORIES LITTLE FUSE 15A
