Agria 3400 - Page 14

14 agria Two-Wheel Tractor 3400; 3400 KL
1 Generator 12 V
2 Regulator
3 Socket (optional Article 3479 911)
4 10 A Flat plug fuse
4.1 20 A glass tube fuse
5 E-Starter
6 Start switch
7 Beeper
8 Battery
9 Central connector for regulator
11 Solenoid clutch
12 Soft start module
13 Distributor
15 Operating hour counter
16 Relay
17 Relay
18 Switch, open (dead man's handle)
19 Push switch
20 Switch, closed (clutch lever)
Electrical Wiring
Diesel Engine / E-Starter Version
ge = yellow
gn = green
gr = grey
ro = red
bl = blue
br = brown
ws = white
L = Steering Handle
S = Switching Unit/
Engine
