Aichi SR12C - Collision Hazards

󱒨󱓍󱓆󱓕󱓙󱓊󱓗󱒅󱒖󱒅󱒒󱒅󱒸󱓆󱓋󱓊󱓙󱓞󱒅󱒷󱓚󱓑󱓊󱓘
4
 CollisionHazards4.
WARNING
• Beforetraveling,checkthearrowdecals
affixedonthechassistomakesurethe
travelingdirectionofthemachine.
M085D122
Forward
(Green)
Backward
(Red)
Forward
(Green)
Backward
(Red)
fig.1‒15
• Makesurethatnopersonorobstacleis
aroundthemachine.Beawareofblind
spotswhentravelingoroperating.If
yourvisionispoor,haveaguidetoassist
you.
• Theturntableprotrudes850mm
beyondthewidthofthechassiswhen
rotatingtheboom,sowatchthe
turntablemovementandmakesure
thatnopersonorobstacleisaroundthe
turntable.
M0863201
850mm
fig.1‒16
• Checktheworkareaforoverhead
obstaclesorotherpossiblehazards.
• Donothitstructuresetc.withthe
platformwhiletraveling.
M085E901
fig.1‒17
• Donothitthegroundwiththeplatform.
M085F100
fig.1‒18
• Oncetheplatformisraised,donotallow
peopleorthingsundertheplatform.
M07Y9J02
fig.1‒19
• Donotlowertheboomunlessthearea
belowisclearofpersonsandobstacles.
• Whenyouareobligedtogetunder
theboomandplatformtoperform
theinspectionsorrepairs,useasafety
supporttopreventtheboomandthe
platformfromunexpecteddescent.
• Donotdropthingsfromtheplatform.
Thereisahazardthatfallingobjectswill
hitcars,orpeoplethatarepassingby.
M07Y9L02
fig.1‒20
• Takecarethatyourhandsonthe
guardrailsarenotcaughtinother
obstacles.
